Tripp
UPC:
UNSPSC:
43211503
MFG:
U442-DOCK24DL3A
TRIPPLITE U442-DOCK24DL3A
Out of stock
TRIPPLITE U442-DOCK24DL3A
Product Specifications
| Primary Information | |
|---|---|
| Product Description | Eaton Tripp Lite Series - docking station - USB-C 3.2 Gen 2 / Thunderbolt 3 - 3 x HDMI, 2 x DP - 1GbE, 2.5GbE |
| Product Type | Docking station |
| Docking Interface | USB-C 3.2 Gen 2 / Thunderbolt 3 |
| Video Interfaces | 3 x HDMI, 2 x DP |
| Dimensions (WxDxH) | 8.9 in x 3.3 in x 1 in |
| Weight | 15.87 oz |
| Color | Black, silver |
| Localization | North America |
| Networking | Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Power | Power adapter AC 100-240 V (50/60 Hz) 149.1 Watt Power Provided (DC 21 V) |
| Manufacturer Warranty | 1-year warranty |
| Designed For | P/N: GC3000L, N201-003-BK-BP, N201-003-BL-BP, N201-005-BL-BP, N201-007-BK-BP, N201-007-BL-BP, N201-010-BK-BP, N201-012-BLTAA, N201-06N-BK-BP, N201-150-WH, P569-006-SLIM-W, P569-010-SLIM, P569-010-SLIM-W, P569-A10-MF-8K6, P569-A15-MF-8K6, P569-A20-MF-8K6, P569-A25-MF-8K6, P580-025-8K6 |
| General | |
| Product Type | Docking station |
| Width | 8.9 in |
| Depth | 3.3 in |
| Height | 1 in |
| Weight | 15.87 oz |
| Enclosure Color | Black, silver |
| Localization | North America |
| Video | |
| Max Resolution Details | 3840 x 2160 - 60 Hz (Triple Display) |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Compliant Standards | USB 3.2 Gen 1, USB 3.2 Gen 2 |
| Expansion / Connectivity | |
| Interfaces | 1 x USB-C 3.2 Gen 2 with Power Delivery 3.0 (100 W) - 24 pin USB-C ¦ 3 x display / video - HDMI - 19 pin HDMI Type A ¦ 2 x display / video - DisplayPort - 20 pin DisplayPort ¦ 1 x network - 10Base-T/100Base-T/1000Base-T/2500Base-T - RJ-45 ¦ 1 x USB-C (host) - 24 pin USB-C ¦ 3 x USB 3.2 Gen 1 - 9 pin USB Type A ¦ 1 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x headphone/microphone combo jack - mini-phone stereo 3.5 mm |
| Miscellaneous | |
| Cables Included | USB-C host cable - external - 4 ft |
| Features | Triple display support, DisplayPort Alt Mode, Extended Mode, MST (multi-stream transport), SST (single-stream transport), Mirror Mode, 36-bit Deep Color, HDR support, 3D video support, 4:4:4 chroma subsampling, unidirectional data flow, up to 48 GB/s bandwidth, Display Stream Compression (DSC), LED status indicators, suspend mode support, security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington nano security slot / Kensington security slot |
| Compliant Standards | RoHS, HDCP 1.4, HDCP 2.3, DisplayPort 1.4, EDID compatible, CTIA, USB Power Delivery 3.0, CAN/CSA-C22.2 No. 62368-1, UL 62368-1, FCC, WEEE |
| Power | |
| Power Device | Power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 149.1 Watt |
| Voltage Provided | DC 21 V |
| System Requirements | |
| OS Required | Microsoft Windows, Apple MacOS, Google Chrome OS, Linux, Android, Ubuntu |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 11.9 in |
| Shipping Depth | 5.1 in |
| Shipping Height | 3.2 in |
| Shipping Weight | 2.65 lbs |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Compatibility Information | |
| Designed For | P/N: 0N201-005-BK, GC3000L, N201-001-BL-LONGS DRUGS, N201-001-BL-LONGSDRUGSPRE, N201-001-OR-INVENERGY, N201-001-WH-LONGS DRUGS, N201-001-YW-INVENERGY, N201-002-GY-LBL, N201-003-BK-BP, N201-003-BL-BP, N201-004-BL-LONGS DRUGS, N201-004-BL-LONGSDRUGSPRE, N201-005-BL-BP, N201-005-OR-INVENERGY, N201-005-YW-INVENERGY, N201-007-BK-BP, N201-007-BL-BP, N201-007-BL-LONGS DRUGS, N201-007-BL-LONGSDRUGSPRE, N201-007-OR-INVENERGY, N201-007-WH-LONGS DRUGS, N201-007-WH-LONGSDRUGSPRE, N201-007-YW-INVENERGY, N201-008-BL-LONGS DRUGS, N201-008-BL-LONGSDRUGSPRE, N201-010-BK-BP, N201-010-BL-LONGS DRUGS, N201-010-BL-LONGSDRUGSPRE, N201-010-YW-INVENERGY, N201-012-BLTAA, N201-014-YW-ADVENT HEALTH, N201-020-BL-CS, N201-020-YW-INVENERGY, N201-025-BL-PAYPAL, N201-025-YW-INVENERGY, N201-030-GY-AMAZON, N201-050-BL-CS, N201-050-YW-INVENERGY, N201-06N-BK-BP, N201-06N-OR, N201-150-WH, N201L-01M-BL, N201L-02M-BL, N201L-03M-BL, N201L-04M-BL, N201L-05M-BL, N201L-07M-BL, N201L-0P5M-BL, N201L-10M-BL, N201L-15M-BL, N201L-1P5M-BL, N201L-2P5M-BL, N201L-3P5M-BL, N201-S01-BK-INVENERGY, N201-S01-BL-INVENERGY, N201-S04-BL-2LB, N201-S05-BK-INVENERGY, N201-S05-BL-2LB, N201-S05-BL-INVENERGY, N201-S06-BL-2LB, N201-S07-BK-INVENERGY, N201-S07-BL-INVENERGY, N201-S08-BL, N201-S100N-BL, N201-S6N-BL-HERMES, N201-S8N-BL-50, P569-003-2B-MF, P569-003-AJG, P569-003-SLIM-8, P569-003-SLIM-W, P569-006-SLIM-W, P569-010-MF-ACT, P569-010-SLIM, P569-010-SLIM-W, P569-015-MF-ACT, P569-020-CL2, P569-020-IND2, P569-020-MF-ACT, P569-025-2B-MF, P569-025-CL2, P569-025-IND2, P569-14N-MF-PM, P569-18N-CRT-FC, P569-54N, P569-A10-MF-8K6, P569-A15-MF-8K6, P569-A20-MF-8K6, P569-A25-MF-8K6, P569AB-006, P580-001-V4, P580-003-8K6, P580-003-8K6-2, P580-003-V4, P580-006-8K6, P580-006-8K6-2, P580-006-V4, P580-009-8K6, P580-010-V4, P580-015-8K6, P580-015-V4, P580-020-8K6, P580-025-8K6, P580-030-8K6, P580AB-006, P580F3-10M-8K6, P580F3-15M-8K6, P580F3-20M-8K6, P580F3-25M-8K6, P580F3-30M-8K6 |
| Special Feature | |
| COO | VIET NAM |
| UNSPSC Code | |
| UNSPSC Code | 43211503 |
Warehouse Availability
| # | Warehouse Location | Available Quantity | Status |
|---|---|---|---|
| 1 | MFG Drop Shipped | 0 | No Stock |
| 2 | Mississauga,ON | 0 | No Stock |
| 3 | Richmond,BC | 0 | No Stock |
| 4 | Dartmouth,NS | 0 | No Stock |
| 5 | Calgary,AB | 0 | No Stock |
