LENOVO THINKSTATION P7 W53423 16G X2 W11PWS
Out of stock
THINKSTATION P7 - Tower - Intel - Xeon - w5-3423 - 2.1GHz - 12-Core - 4.2GHz - DDR5 - 32GB RAM - 4800MHz - No Hard Drive Capacity / HDD HDD - No Hard Drive / Spindle Speed - 1TB SSD - NVIDIA RTX 4500 ADA - Power Supply - 1400Watt - Intel Wi-Fi 6E AX210 - Gigabit Ethernet,Wi-Fi, Bluetooth - Mouse,Keyboard - Microsoft Windows 11 Professional for Workstations - 3-year
Product Specifications
| Primary Information | |
|---|---|
| System Type | Workstation |
| Model | THINKSTATION P7 |
| Cabinet Form Factor | Tower |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Clock Speed | 2.1 GHz |
| Max Turbo Frequency | 4.2 GHz |
| Processor / Number | w5-3423 |
| Multi-Core Technology | 12-Core |
| Cache Memory Type | Smart Cache |
| Cache Memory Installed Size | 30 MB |
| Processor / Socket Type | FCLGA4677 |
| Mainboard / Chipset Type | Intel W790 |
| RAM / Technology | DDR5 |
| RAM / Total Installed Size | 32 GB |
| RAM / Installed Qty | 2 |
| RAM Form Factor | DIMM |
| RAM / Memory Speed | 4800 MHz |
| RAM / Total Slots Qty | 8 |
| RAM / Max Supported Size | 1 TB |
| 2nd Hard Drive Capacity | None GB |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Interface Type | M.2 |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 1 TB |
| SSD / Installed Qty | 1 |
| RAID Level | None |
| Network Controller | Intel Wi-Fi 6E AX210 |
| Data Link Protocol | Gigabit Ethernet; Wi-Fi, Bluetooth |
| Graphics Controller | NVIDIA RTX 4500 ADA |
| Video Memory / Technology | GDDR6 |
| Video Memory / Installed Size | 24 GB |
| Input Device Support Type | Mouse; Keyboard |
| Keyboard | USB Traditional Keyboard, Black, English |
| Mouse | USB Calliope Mouse, Black |
| Operating System | Microsoft Windows 11 Professional for Workstations |
| Interfaces & Connections | 2x RJ-45, GbE + 10GbE, 1x headphone / microphone combo jack (3.5mm), 1x USB-C 3.2 Gen 2x2 (support data transfer), 2x USB 2.0, 3x USB 3.2 Gen 2, 1x Ethernet (10GbE RJ-45), 1x Ethernet (GbE RJ-45), 1x line-in (3.5mm), 1x line-out (3.5mm) |
| Front I/O Ports | 1x headphone / microphone combo jack (3.5mm) |
| Rear I/O Ports | 1x USB-C 3.2 Gen 2x2 (support data transfer), 2x USB 2.0, 3x USB 3.2 Gen 2, 1x Ethernet (10GbE RJ-45), 1x Ethernet (GbE RJ-45), 1x line-in (3.5mm), 1x line-out (3.5mm) |
| Service & Support Type | 3-year |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Expansion Slots Total (Free) | Supports 7 PCIe slots with 4x PCIe 5.0 slots and 3x PCIe 4.0 slots |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 1400 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Efficiency | 92% |
| Width | 6.9 Inch |
| Depth | 20 Inch |
| Height | 17.1 Inch |
| Weight | 24.5 Kg |
| Enclosure Color | Black |
| Min Operating Temperature | 10 CELSIUS |
| Max Operating Temperature | 35 CELSIUS |
| Humidity Range Operating | 20% to 80% |
| Processor | |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Clock Speed | 2.1 GHz |
| Processor / Number | w5-3423 |
| Cache Memory Type | Smart Cache |
| Cache Memory Installed Size | 30 MB |
| Multi-Core Technology | 12-Core |
| Processor / Socket Type | FCLGA4677 |
| Memory | |
| RAM / Technology | DDR5 |
| RAM / Total Installed Size | 32 GB |
| RAM / Installed Qty | 2 |
| RAM / Total Slots Qty | 8 |
| RAM / Max Supported Size | 1 TB |
| Storage | |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Interface Type | M.2 |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 1 TB |
| 2nd Hard Drive Capacity | None GB |
| SSD / Installed Qty | 1 |
| RAID Level | None |
| Software | |
| Service & Support Type | 3-year |
| Networking | |
| Network Controller | Intel Wi-Fi 6E AX210 |
| Data Link Protocol | Wi-Fi, Bluetooth; Gigabit Ethernet |
| Expansion | |
| Interfaces & Connections | 2x RJ-45, GbE + 10GbE, 1x headphone / microphone combo jack (3.5mm), 1x USB-C 3.2 Gen 2x2 (support data transfer), 2x USB 2.0, 3x USB 3.2 Gen 2, 1x Ethernet (10GbE RJ-45), 1x Ethernet (GbE RJ-45), 1x line-in (3.5mm), 1x line-out (3.5mm) |
| Front I/O Ports | 1x headphone / microphone combo jack (3.5mm) |
| Rear I/O Ports | 1x USB-C 3.2 Gen 2x2 (support data transfer), 2x USB 2.0, 3x USB 3.2 Gen 2, 1x Ethernet (10GbE RJ-45), 1x Ethernet (GbE RJ-45), 1x line-in (3.5mm), 1x line-out (3.5mm) |
| Expansion Slots Total (Free) | Supports 7 PCIe slots with 4x PCIe 5.0 slots and 3x PCIe 4.0 slots |
| Power | |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 1400 Watt |
| Dimensions&Miscellaneous | |
| Width | 6.9 Inch |
| Depth | 20 Inch |
| Height | 17.1 Inch |
| Enclosure Color | Black |
| Weight | 24.5 Kg |
| Special Feature | |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| COO | MEXICO |
| UNSPSC Code | |
| UNSPSC Code | 43211515 |
