Lenovo
UPC:
197531482891
UNSPSC:
43211508
MFG:
12DN0014US
LENOVO ENG DESKTOP TC M70S GEN 4 I513400 16G N W11P
Out of stock
ThinkCentre M70s Gen 4, Intel Core i5-13400 (E-cores up to 3.30GHz, 20MB), W11P64 ENG, 16.0GB, 1x256GB SSD M.2 2280 PCIe Gen4 TLC Opal, Intel UHD Graphics 730, Slim DVD RAMBO,BT 5.3,IntelAX211vPro, 260W, 3 Year On-site, USB, Traditional, Black-English (US), USB Calliope Mouse (Black)
Product Specifications
| General | |
|---|---|
| Processor | Intel,Intel Core i5,Core i5 2.5,2.5GHz Smart Cache,Smart Cache 13400,13400 Cache Memory 20,20MB Max Turbo 4.6,4.6GHz |
| RAM | DIMM,DIMM DDR4,DDR4 Total Installed 16,16GB 3200,3200MHz Max Supported 128,128GB |
| Primary Information | |
| System Type | Personal Computer |
| Model | Lenovo ThinkCentre M70s Gen4(Intel) |
| Cabinet Form Factor | Small Form Factor |
| Processor / Generation | Intel 13th Generation |
| Processor / Type | Core i5 |
| Processor / Manufacturer | Intel |
| Multi-Core Technology | 10-Core |
| Processor / Clock Speed | 2.5 GHz |
| Cache Memory Installed Size | 20 MB |
| Max Turbo Frequency | 4.6 GHz |
| Processor / Number | 13400 |
| Processor / Installed Qty | 1 |
| RAM / Installed Qty | 1 |
| Mainboard / Chipset Type | Intel Q670 |
| RAM / Technology | DDR4 |
| RAM / Total Slots Qty | 4 |
| RAM / Total Installed Size | 16 GB |
| RAM / Memory Speed | 3200 MHz |
| RAM Form Factor | DIMM |
| RAM / Max Supported Size | 128 GB |
| Storage Controller Type | M.2 |
| Hard Drive / Type | SSD |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 256 GB |
| SSD / Installed Qty | 1 |
| Optical Storage Type | DVD+/-RW |
| Audio Output | High Definition (HD) Audio, Realtek ALC897Q-CG codec |
| Memory Card Reader | None |
| Hard Drive / Capacity (2nd) | None GB |
| Graphics Controller | Intel UHD Graphics 730 |
| Video Memory / Technology | None |
| Video Memory / Installed Size | None GB |
| Video Output Interface | Display Port, HDMI |
| Speakers | 1 x 1W |
| Keyboard Language | English |
| Keyboard | USB Traditional Keyboard, Black, English |
| Mouse | USB Calliope Mouse, Black |
| Operating System | Microsoft Windows 11 Pro |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 260 Watt |
| Efficiency | 90% |
| Interfaces & Connections | 1x USB-C 3.2 Gen 1 (15W charging); 2x USB 3.2 Gen 1; 2x USB 3.2 Gen 2; 1x headphone / microphone combo jack (3.5mm); 1x microphone (3.5mm); 4x USB 2.0; 1x HDMI 2.1 TMDS; 2x DisplayPort 1.4a (HBR2, DSC); 1x Ethernet (RJ-45); 1x line-out (3.5mm) |
| Front I/O Ports | 1x USB-C 3.2 Gen 1 (15W charging); 2x USB 3.2 Gen 1; 2x USB 3.2 Gen 2; 1x headphone / microphone combo jack (3.5mm); 1x microphone (3.5mm) |
| Rear I/O Ports | 4x USB 2.0; 1x HDMI 2.1 TMDS; 2x DisplayPort 1.4a (HBR2, DSC); 1x Ethernet (RJ-45); 1x line-out (3.5mm) |
| Expansion Slots Total (Free) | One PCIe 4.0 x16, low-profile, length <= 155mm, height <= 70mm; Two PCIe 3.0 x1, low-profile, length <= 155mm, height <= 70mm; Two M.2 slots (one for WLAN, one for SSD) |
| Width | 3.6 Inch |
| Depth | 11.7 Inch |
| Height | 13.4 Inch |
| Weight | 5.3 Kg |
| Enclosure Color | Black |
| Service & Support Type | 3 Year On-site |
| Security Devices | Discrete TPM 2.0 |
| Features | Integrated 100/1000M |
| Stand | Yes |
| Memory | |
| Cache Memory Type | Smart Cache |
| RAM / Installed Qty | 1 |
| RAM / Total Slots Qty | 4 |
| RAM / Technology | DDR4 |
| RAM / Total Installed Size | 16 GB |
| RAM / Memory Speed | 3200 MHz |
| RAM Form Factor | DIMM |
| RAM / Max Supported Size | 128 GB |
| Processor | |
| Processor / Generation | Intel 13th Generation |
| Processor / Type | Core i5 |
| Processor / Manufacturer | Intel |
| Multi-Core Technology | 10-Core |
| Processor / Clock Speed | 2.5 GHz |
| Max Turbo Frequency | 4.6 GHz |
| Processor / Number | 13400 |
| Processor / Installed Qty | 1 |
| Cache Memory Type | Smart Cache |
| Cache Memory Installed Size | 20 MB |
| Storage | |
| Hard Drive / Type | SSD |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 256 GB |
| SSD / Installed Qty | 1 |
| Optical Storage Type | DVD+/-RW |
| Storage Controller Type | M.2 |
| Hard Drive / Capacity (2nd) | None GB |
| Expansion | |
| Interfaces & Connections | 1x USB-C 3.2 Gen 1 (15W charging); 2x USB 3.2 Gen 1; 2x USB 3.2 Gen 2; 1x headphone / microphone combo jack (3.5mm); 1x microphone (3.5mm); 4x USB 2.0; 1x HDMI 2.1 TMDS; 2x DisplayPort 1.4a (HBR2, DSC); 1x Ethernet (RJ-45); 1x line-out (3.5mm) |
| Expansion Slots Total (Free) | One PCIe 4.0 x16, low-profile, length <= 155mm, height <= 70mm; Two PCIe 3.0 x1, low-profile, length <= 155mm, height <= 70mm; Two M.2 slots (one for WLAN, one for SSD) |
| Front I/O Ports | 1x USB-C 3.2 Gen 1 (15W charging); 2x USB 3.2 Gen 1; 2x USB 3.2 Gen 2; 1x headphone / microphone combo jack (3.5mm); 1x microphone (3.5mm) |
| Rear I/O Ports | 4x USB 2.0; 1x HDMI 2.1 TMDS; 2x DisplayPort 1.4a (HBR2, DSC); 1x Ethernet (RJ-45); 1x line-out (3.5mm) |
| I/O | |
| Keyboard | USB Traditional Keyboard, Black, English |
| Mouse | USB Calliope Mouse, Black |
| Keyboard Language | English |
| Power | |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 260 Watt |
| Efficiency | 90% |
| Special Feature | |
| Security Devices | Discrete TPM 2.0 |
| COO | MEXICO |
| Video | |
| Graphics Controller | Intel UHD Graphics 730 |
| Video Memory / Technology | None |
| Video Memory / Installed Size | None GB |
| Video Output Interface | Display Port, HDMI |
| Dimensions&Miscellaneous | |
| Enclosure Color | Black |
| Width | 3.6 Inch |
| Depth | 11.7 Inch |
| Height | 13.4 Inch |
| Weight | 5.3 Kg |
| UNSPSC Code | |
| UNSPSC Code | 43211508 |
