Lenovo
UPC:
198153582938
UNSPSC:
43211508
MFG:
12TA000TCA
LENOVO DESKTOP TC M75S GEN 5 A3P8300G 16G N W11
Out of stock
ThinkCentre M75s Gen 5 - Small Form Factor - AMD - AMD Ryzen 3 PRO - 8300G - Processor / Clock Speed: 3.4 - Quad-Core - Max Turbo Frequency: 4.9 - DDR5 UDIMM - RAM / Total Installed Size: 16 RAM - RAM / Memory Speed: 5200 - Hard Drive Capacity / SSD: 256 SSD - DVD+-RW - AMD Radeon 740M - Power Supply - Power / Provided (W): 260 - IEEE 802.11 ax, Bluetooth 5.3 - Keyboard, Mouse - Black - Microsoft Windows 11 Professional - 3-year, Onsite Warranty
Product Specifications
| Primary Information | |
|---|---|
| System Type | Personal Computer |
| Model | ThinkCentre M75s Gen 5 |
| Cabinet Form Factor | Small Form Factor |
| Processor / Type | AMD Ryzen 3 PRO |
| Processor / Manufacturer | AMD |
| Multi-Core Technology | Quad-Core |
| Processor / Clock Speed | 3.4 GHz |
| Cache Memory Installed Size | 8 MB |
| Max Turbo Frequency | 4.9 GHz |
| Processor / Number | 8300G |
| Processor / Installed Qty | 1 |
| RAM / Installed Qty | 1 |
| Mainboard / Chipset Type | AMD PRO 665 |
| RAM / Technology | DDR5 UDIMM |
| RAM / Total Slots Qty | 2 |
| RAM / Total Installed Size | 16 GB |
| RAM / Memory Speed | 5200 MHz |
| RAM Form Factor | UDIMM |
| RAM / Max Supported Size | 64 GB |
| Storage Controller Type | M.2 |
| Hard Drive / Type | SSD |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Interface Type | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 256 GB |
| Optical Storage Type | DVD+-RW |
| Audio Output | High Definition (HD) Audio, Realtek ALC623-CG codec |
| Memory Card Reader | None |
| Hard Drive / Capacity (2nd) | None GB |
| RAID Level | RAID 0, 1 |
| Data Link Protocol | IEEE 802.11 ax, Bluetooth 5.3 |
| Graphics Controller | AMD Radeon 740M |
| Speakers | 1 x 1W |
| Input Device Support Type | Keyboard, Mouse |
| Keyboard Language | French |
| Keyboard | USB Traditional Keyboard, Black, French |
| Mouse | USB Calliope Mouse, Black |
| Operating System | Microsoft Windows 11 Professional |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 260 Watt |
| Efficiency | 90% |
| Interfaces & Connections | 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging, 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x headphone / microphone combo jack (3.5mm), 1x microphone (3.5mm); 4x USB-A (Hi-Speed USB / USB 2.0), 1x HDMI 2.1 TMDS, 2x DisplayPort 1.4a (HBR2, DSC), 1x Ethernet (RJ-45), 1x line-out (3.5mm) |
| Front I/O Ports | 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging, 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x headphone / microphone combo jack (3.5mm), 1x microphone (3.5mm) |
| Rear I/O Ports | 4x USB-A (Hi-Speed USB / USB 2.0), 1x HDMI 2.1 TMDS, 2x DisplayPort 1.4a (HBR2, DSC), 1x Ethernet (RJ-45), 1x line-out (3.5mm) |
| Expansion Slots Total (Free) | One PCIe 3.0 x16, low-profile, length 155mm, height 70mm, One PCIe 3.0 x1, low-profile, length 155mm, height 70mm, Three M.2 slots (one for WLAN, two for SSD) |
| Width | 3.6 Inch |
| Depth | 11.7 Inch |
| Height | 13.4 Inch |
| Weight | 10.1 lbs. |
| Enclosure Color | Black |
| Service & Support Type | 3-year, Onsite Warranty |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Features | Integrated 100/1000M |
| Stand | None |
| Memory | |
| Cache Memory Type | L3 cache |
| RAM / Installed Qty | 1 |
| RAM / Total Slots Qty | 2 |
| RAM / Technology | DDR5 UDIMM |
| RAM / Total Installed Size | 16 GB |
| RAM / Memory Speed | 5200 MHz |
| RAM Form Factor | UDIMM |
| RAM / Max Supported Size | 64 GB |
| Processor | |
| Processor / Type | AMD Ryzen 3 PRO |
| Processor / Manufacturer | AMD |
| Multi-Core Technology | Quad-Core |
| Processor / Clock Speed | 3.4 GHz |
| Max Turbo Frequency | 4.9 GHz |
| Processor / Number | 8300G |
| Processor / Installed Qty | 1 |
| Cache Memory Type | L3 cache |
| Cache Memory Installed Size | 8 MB |
| Storage | |
| Hard Drive / Type | SSD |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Interface Type | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 256 GB |
| Optical Storage Type | DVD+-RW |
| Storage Controller Type | M.2 |
| Hard Drive / Capacity (2nd) | None GB |
| RAID Level | RAID 0, 1 |
| Expansion | |
| Interfaces & Connections | 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging, 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x headphone / microphone combo jack (3.5mm), 1x microphone (3.5mm); 4x USB-A (Hi-Speed USB / USB 2.0), 1x HDMI 2.1 TMDS, 2x DisplayPort 1.4a (HBR2, DSC), 1x Ethernet (RJ-45), 1x line-out (3.5mm) |
| Expansion Slots Total (Free) | One PCIe 3.0 x16, low-profile, length 155mm, height 70mm, One PCIe 3.0 x1, low-profile, length 155mm, height 70mm, Three M.2 slots (one for WLAN, two for SSD) |
| Front I/O Ports | 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging, 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x headphone / microphone combo jack (3.5mm), 1x microphone (3.5mm) |
| Rear I/O Ports | 4x USB-A (Hi-Speed USB / USB 2.0), 1x HDMI 2.1 TMDS, 2x DisplayPort 1.4a (HBR2, DSC), 1x Ethernet (RJ-45), 1x line-out (3.5mm) |
| I/O | |
| Input Device Support Type | Keyboard, Mouse |
| Keyboard | USB Traditional Keyboard, Black, French |
| Mouse | USB Calliope Mouse, Black |
| Keyboard Language | French |
| Networking | |
| Data Link Protocol | IEEE 802.11 ax, Bluetooth 5.3 |
| Power | |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 260 Watt |
| Efficiency | 90% |
| Special Feature | |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| COO | MEXICO |
| Video | |
| Graphics Controller | AMD Radeon 740M |
| Dimensions&Miscellaneous | |
| Enclosure Color | Black |
| Width | 3.6 Inch |
| Depth | 11.7 Inch |
| Height | 13.4 Inch |
| Weight | 10.1 lbs. |
| UNSPSC Code | |
| UNSPSC Code | 43211508 |
Warehouse Availability
| # | Warehouse Location | Available Quantity | Status |
|---|---|---|---|
| 1 | MFG Drop Shipped | 0 | No Stock |
| 2 | Mississauga,ON | 0 | No Stock |
| 3 | Richmond,BC | 0 | No Stock |
| 4 | Dartmouth,NS | 0 | No Stock |
| 5 | Calgary,AB | 0 | No Stock |
