Lenovo
UPC:
198157007925
UNSPSC:
43211508
MFG:
13AY000AUS
LENOVO DESKTOP TC M70A GEN 6 U5225T 16G 256G W1
Out of stock
LENOVO DESKTOP TC M70A GEN 6 U5225T 16G 256G W1
Product Specifications
| General | |
|---|---|
| Processor | Intel,Intel Core Ultra 5,Core Ultra 5 2.5,2.5GHz 3,3 Smart Cache,Smart Cache 225T,225T Cache Memory 20,20MB Max Turbo 4.9,4.9GHz |
| RAM | SODIMM,SODIMM DDR5,DDR5 Total Installed 16,16GB 5600,5600MHz Max Supported 64,64GB |
| Primary Information | |
| System Type | AI PC |
| Model | ThinkCentre M70a Gen 6 |
| Cabinet Form Factor | All-in-one |
| Processor / Type | Core Ultra 5 |
| Processor / Manufacturer | Intel |
| Multi-Core Technology | 10-Core |
| Processor / Clock Speed | 2.5 GHz |
| Cache Memory Installed Size | 20 MB |
| Max Turbo Frequency | 4.9 GHz |
| Processor / Number | 225T |
| Processor / Installed Qty | 1 |
| Processor / Max Supported Qty | 1 |
| Neural Processor Unit (NPU) | Intel AI Boost |
| Mainboard / Chipset Type | Intel Q870 |
| RAM / Technology | DDR5 |
| RAM / Total Slots Qty | 2 |
| RAM / Total Installed Size | 16 GB |
| RAM / Memory Speed | 5600 MHz |
| RAM Form Factor | SODIMM |
| RAM / Max Supported Size | 64 GB |
| Storage Controller Type | M.2 |
| Hard Drive / Type | SSD |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 256 GB |
| SSD / Installed Qty | 1 |
| Audio Output | High Definition (HD) Audio |
| Hard Drive / Capacity (2nd) | None GB |
| Graphics Controller | Intel Graphics |
| Video Memory / Installed Size | None GB |
| Max Monitors Supported | 3 |
| Video Output Interface | HDMI; Display Port |
| Speakers | Stereo Speaker |
| Operating System | Microsoft Windows 11 |
| Power / Device Type | Power Adapter |
| Power / Provided (W) | 90 Watt |
| Efficiency | 89% |
| Front I/O Ports | 1x headphone / microphone combo jack (3.5mm); 1x USB-A (USB 10Gbps / USB 3.2 Gen 2); 1x USB-C (USB 10Gbps / USB 3.2 Gen 2), support data transfer and 5V@3A charging |
| Rear I/O Ports | 2x USB-A (USB 10Gbps / USB 3.2 Gen 2); 2x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On; 1x HDMI (HDMI in 1.4 / HDMI out 2.1 TMDS combo port); 1x DisplayPort 1.4a (HBR2); 1x Ethernet (RJ-45) |
| Expansion Bays Total (Free) | No bays |
| Expansion Slots Total (Free) | Three M.2 slots (one for WLAN, two for SSD / discrete NPU) |
| Enclosure Color | Black |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Memory | |
| Cache Memory Type | Smart Cache |
| RAM / Total Slots Qty | 2 |
| RAM / Technology | DDR5 |
| RAM / Total Installed Size | 16 GB |
| RAM / Memory Speed | 5600 MHz |
| RAM Form Factor | SODIMM |
| RAM / Max Supported Size | 64 GB |
| Processor | |
| Processor / Type | Core Ultra 5 |
| Processor / Manufacturer | Intel |
| Multi-Core Technology | 10-Core |
| Processor / Clock Speed | 2.5 GHz |
| Max Turbo Frequency | 4.9 GHz |
| Processor / Number | 225T |
| Processor / Installed Qty | 1 |
| Processor / Max Supported Qty | 1 |
| Cache Memory Type | Smart Cache |
| Cache Memory Installed Size | 20 MB |
| Neural Processor Unit (NPU) | Intel AI Boost |
| Storage | |
| Hard Drive / Type | SSD |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 256 GB |
| SSD / Installed Qty | 1 |
| Storage Controller Type | M.2 |
| Hard Drive / Capacity (2nd) | None GB |
| Expansion | |
| Expansion Bays Total (Free) | No bays |
| Expansion Slots Total (Free) | Three M.2 slots (one for WLAN, two for SSD / discrete NPU) |
| Front I/O Ports | 1x headphone / microphone combo jack (3.5mm); 1x USB-A (USB 10Gbps / USB 3.2 Gen 2); 1x USB-C (USB 10Gbps / USB 3.2 Gen 2), support data transfer and 5V@3A charging |
| Rear I/O Ports | 2x USB-A (USB 10Gbps / USB 3.2 Gen 2); 2x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On; 1x HDMI (HDMI in 1.4 / HDMI out 2.1 TMDS combo port); 1x DisplayPort 1.4a (HBR2); 1x Ethernet (RJ-45) |
| Power | |
| Power / Device Type | Power Adapter |
| Power / Provided (W) | 90 Watt |
| Efficiency | 89% |
| Special Feature | |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| COO | Inquire |
| TAA compliance | Inquire |
| Video | |
| Graphics Controller | Intel Graphics |
| Video Memory / Installed Size | None GB |
| Video Output Interface | HDMI; Display Port |
| Dimensions&Miscellaneous | |
| Enclosure Color | Black |
| UNSPSC Code | |
| UNSPSC Code | 43211508 |
