Lenovo
UPC:
197530264788
UNSPSC:
43211515
MFG:
30F3006SUS
LENOVO THINKSTATION P7 W93495X 16G X4 W11PWS
Out of stock
THINKSTATION P7, INTEL XEON W9-3495X (1.90GHZ, 105MB), WINDOWS 11 PRO FOR WORKSTATIONS 64, 64.0GB, 1X2TB SSD M.2 2280 PCIE GEN4 PERFORMANCE TLC OPAL, NVIDIA RTX 4500 ADA 24GB, INTEL AX210 AX, BT 5.1 OR ABOVE, 3YR PREMIER NBD, USB, TRADITIONAL, BLACK-ENGLISH (US)
Product Specifications
| Primary Information | |
|---|---|
| System Type | Workstation |
| Model | THINKSTATION P7 |
| Cabinet Form Factor | Tower |
| Platform Technology | Intel vPro Enterprise with Intel AMT 16 |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Clock Speed | 1.9 GHz |
| Max Turbo Frequency | 4.8 GHz |
| Processor / Number | w9-3495X |
| Multi-Core Technology | 56-Core |
| Processor / Installed Qty | 1 |
| Processor / Max Supported Qty | 1 |
| Cache Memory Type | Smart Cache |
| Cache Memory Installed Size | 105 MB |
| Processor / Socket Type | FCLGA4677 |
| Mainboard / Chipset Type | Intel W790 |
| RAM / Technology | DDR5 |
| RAM / Total Installed Size | 64 GB |
| RAM / Installed Qty | 4 |
| RAM Form Factor | RDIMM |
| RAM / Memory Speed | 4800 MHz |
| RAM / Total Slots Qty | 8 |
| RAM / Max Supported Size | 1 TB |
| 2nd Hard Drive Capacity | None GB |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 2 TB |
| SSD / Installed Qty | 1 |
| Network Controller | Intel Wi-Fi 6E |
| Data Link Protocol | Ethernet; Wi-Fi, Bluetooth |
| Graphics Controller | NVIDIA RTX 4500 ADA |
| Video Memory / Installed Size | 24 GB |
| Audio Output | High Definition (HD) Audio |
| Input Device Support Type | Keyboard |
| Keyboard | USB Traditional Keyboard, Black, English |
| Mouse | USB Calliope Mouse, Black |
| Operating System | Microsoft Windows 11 Professional 64-bit for Workstations |
| Front I/O Ports | 1x headphone / microphone combo jack (3.5mm) |
| Rear I/O Ports | 1x USB-C 3.2 Gen 2x2 (support data transfer) 2x USB 2.0 3x USB 3.2 Gen 2 1x Ethernet (10GbE RJ-45) 1x Ethernet (GbE RJ-45) 1x line-in (3.5mm) 1x line-out (3.5mm) |
| Service & Support Type | 3-year, Onsite |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Expansion Bays | Bay 1 supports one 3.5" HDD, standard, optional support for M.2 SSD Bay 2 supports one 3.5" HDD, standard, optional support for M.2 SSD |
| Expansion Slots Total (Free) | Supports 7 PCIe slots with 4x PCIe 5.0 slots and 3x PCIe 4.0 slots. Slot 1: PCIe 5.0 x16, full height, full length, 75W, double-width Slot 2: PCIe 4.0 x8, full height, full length, 25W Slot 3: PCIe 5.0 x16, full height, full length, 75W, double-width Slot 4: PCIe 4.0 x4, full height, full length, 25W Slot 5: PCIe 5.0 x16, full height, full length, 75W, double-width Slot 6: PCIe 4.0 x16, full height, full length, 75W Slot 7: PCIe 5.0 x4, full height, full length, 25W |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 1400 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Width | 6.9 Inch |
| Depth | 20 Inch |
| Height | 17.1 Inch |
| Weight | 24.5 Kg |
| Min Operating Temperature | 10C |
| Max Operating Temperature | 35C |
| Humidity Range Operating | Operating: 20% to 80% |
| Processor | |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Clock Speed | 1.9 GHz |
| Processor / Number | w9-3495X |
| Processor / Installed Qty | 1 |
| Processor / Max Supported Qty | 1 |
| Cache Memory Type | Smart Cache |
| Cache Memory Installed Size | 105 MB |
| Multi-Core Technology | 56-Core |
| Processor / Socket Type | FCLGA4677 |
| Memory | |
| RAM / Technology | DDR5 |
| RAM / Total Installed Size | 64 GB |
| RAM / Installed Qty | 4 |
| RAM / Total Slots Qty | 8 |
| RAM / Max Supported Size | 1 TB |
| Storage | |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 2 TB |
| 2nd Hard Drive Capacity | None GB |
| SSD / Installed Qty | 1 |
| Software | |
| Service & Support Type | 3-year, Onsite |
| Networking | |
| Network Controller | Intel Wi-Fi 6E |
| Data Link Protocol | Wi-Fi, Bluetooth; Ethernet |
| Expansion | |
| Front I/O Ports | 1x headphone / microphone combo jack (3.5mm) |
| Rear I/O Ports | 1x USB-C 3.2 Gen 2x2 (support data transfer) 2x USB 2.0 3x USB 3.2 Gen 2 1x Ethernet (10GbE RJ-45) 1x Ethernet (GbE RJ-45) 1x line-in (3.5mm) 1x line-out (3.5mm) |
| Expansion Bays | Bay 1 supports one 3.5" HDD, standard, optional support for M.2 SSD Bay 2 supports one 3.5" HDD, standard, optional support for M.2 SSD |
| Expansion Slots Total (Free) | Supports 7 PCIe slots with 4x PCIe 5.0 slots and 3x PCIe 4.0 slots. Slot 1: PCIe 5.0 x16, full height, full length, 75W, double-width Slot 2: PCIe 4.0 x8, full height, full length, 25W Slot 3: PCIe 5.0 x16, full height, full length, 75W, double-width Slot 4: PCIe 4.0 x4, full height, full length, 25W Slot 5: PCIe 5.0 x16, full height, full length, 75W, double-width Slot 6: PCIe 4.0 x16, full height, full length, 75W Slot 7: PCIe 5.0 x4, full height, full length, 25W |
| Power | |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 1400 Watt |
| Dimensions&Miscellaneous | |
| Width | 6.9 Inch |
| Depth | 20 Inch |
| Height | 17.1 Inch |
| Weight | 24.5 Kg |
| Special Feature | |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| COO | MEXICO |
| UNSPSC Code | |
| UNSPSC Code | 43211515 |
Warehouse Availability
| # | Warehouse Location | Available Quantity | Status |
|---|---|---|---|
| 1 | MFG Drop Shipped | 0 | No Stock |
| 2 | Mississauga,ON | 0 | No Stock |
| 3 | Richmond,BC | 0 | No Stock |
| 4 | Dartmouth,NS | 0 | No Stock |
| 5 | Calgary,AB | 0 | No Stock |
