Lenovo
UPC:
196804817576
UNSPSC:
43211515
MFG:
30F30014US
LENOVO ENG THINKSTATION P7 W73455 16G X8 W11PWS
Out of stock
ThinkStation P7 - Intel - Xeon - W7-3455 (2.50GHz - 67.5MB) - Windows 11 Pro for Workstations 64 - 128.0GB - 1x1TB SSD M.2 2280 PCIe Gen4 Performance TLC Opal - NVIDIA - T1000 8GB - 3 Year Premier NBD - USB - Traditional - Black-English (US)
Product Specifications
| Primary Information | |
|---|---|
| System Type | Workstation |
| Model | Thinkstation P7 |
| Cabinet Form Factor | Desktop |
| Platform Technology | Intel vPro Enterprise with Intel AMT 16 |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Clock Speed | 2.5 GHz |
| Max Turbo Frequency | 4.8 GHz |
| Processor / Number | w7-3455 |
| Multi-Core Technology | 24-Core |
| Processor / Installed Qty | 1 |
| Processor / Max Supported Qty | 1 |
| Cache Memory Type | Smart Cache |
| Cache Memory Installed Size | 67.5 MB |
| Processor / Socket Type | FCLGA4677 |
| Mainboard / Chipset Type | Intel W790 |
| RAM / Technology | DDR5 |
| RAM / Total Installed Size | 128 GB |
| RAM / Installed Qty | 8 |
| RAM Form Factor | RDIMM |
| RAM / Memory Speed | 4800 MHz |
| RAM / Total Slots Qty | 8 |
| RAM / Max Supported Size | 1 TB |
| 2nd Hard Drive Capacity | None GB |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Interface Type | PCIe NVMe Gen4 x4 |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 1 TB |
| SSD / Installed Qty | 1 |
| RAID Level | None |
| Network Controller | Intel Ethernet Connection I219-LM and Marvell AQtion AQC-113C |
| Data Link Protocol | Gigabit Ethernet |
| Graphics Controller | NVIDIA T1000 |
| Video Memory / Technology | GDDR6 |
| Video Memory / Installed Size | 8 GB |
| Video Interfaces | Mini Displayport |
| Audio Output | High Definition (HD) Audio, Realtek ALC897-Q codec |
| Input Device Support Type | Keyboard, Mouse |
| Keyboard | USB Traditional Keyboard, Black, English |
| Mouse | USB Calliope Mouse, Black |
| Operating System | Microsoft Windows 11 Professional |
| Interfaces & Connections | Front Ports: 1x headphone / microphone combo jack (3.5mm); Rear Ports: 1x USB-C 3.2 Gen 2x2 (support data transfer), 2x USB 2.0, 3x USB 3.2 Gen 2, 1x Ethernet (10GbE RJ-45), 1x Ethernet (GbE RJ-45), 1x line-in (3.5mm), 1x line-out (3.5mm) |
| Front I/O Ports | 1x headphone / microphone combo jack (3.5mm); |
| Rear I/O Ports | 1x USB-C 3.2 Gen 2x2 (support data transfer), 2x USB 2.0, 3x USB 3.2 Gen 2, 1x Ethernet (10GbE RJ-45), 1x Ethernet (GbE RJ-45), 1x line-in (3.5mm), 1x line-out (3.5mm) |
| Service & Support Type | 3-Year, Onsite Base Warranty |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified, Kensington Security Slot, 3 x 7 mm |
| Expansion Bays | Bay 1 supports one 3.5" HDD, standard, optional support for M.2 SSD, Bay 2 supports one 3.5" HDD, standard, optional support for M.2 SSD |
| Expansion Slots Total (Free) | 7 PCIe slots with 4x PCIe 5.0 slots and 3x PCIe 4.0 slots |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 1400 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Efficiency | 92% |
| Width | 6.9 Inch |
| Depth | 20 Inch |
| Height | 17.1 Inch |
| Weight | 24.5 Kg |
| Min Operating Temperature | 10 Celsius Degree |
| Max Operating Temperature | 35 Celsius Degree |
| Humidity Range Operating | 20% to 80% |
| Processor | |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Clock Speed | 2.5 GHz |
| Processor / Number | w7-3455 |
| Processor / Installed Qty | 1 |
| Processor / Max Supported Qty | 1 |
| Cache Memory Type | Smart Cache |
| Cache Memory Installed Size | 67.5 MB |
| Multi-Core Technology | 24-Core |
| Processor / Socket Type | FCLGA4677 |
| Memory | |
| RAM / Technology | DDR5 |
| RAM / Total Installed Size | 128 GB |
| RAM / Installed Qty | 8 |
| RAM / Total Slots Qty | 8 |
| RAM / Max Supported Size | 1 TB |
| Storage | |
| Hard Drive Capacity / HDD | None GB |
| Hard Drive / Installed Qty | None |
| Hard Drive / Interface Type | PCIe NVMe Gen4 x4 |
| Hard Drive / Spindle Speed | None RPM |
| SSD Capacity | 1 TB |
| 2nd Hard Drive Capacity | None GB |
| SSD / Installed Qty | 1 |
| RAID Level | None |
| Software | |
| Service & Support Type | 3-Year, Onsite Base Warranty |
| Networking | |
| Network Controller | Intel Ethernet Connection I219-LM and Marvell AQtion AQC-113C |
| Data Link Protocol | Gigabit Ethernet |
| Expansion | |
| Interfaces & Connections | Front Ports: 1x headphone / microphone combo jack (3.5mm); Rear Ports: 1x USB-C 3.2 Gen 2x2 (support data transfer), 2x USB 2.0, 3x USB 3.2 Gen 2, 1x Ethernet (10GbE RJ-45), 1x Ethernet (GbE RJ-45), 1x line-in (3.5mm), 1x line-out (3.5mm) |
| Front I/O Ports | 1x headphone / microphone combo jack (3.5mm); |
| Rear I/O Ports | 1x USB-C 3.2 Gen 2x2 (support data transfer), 2x USB 2.0, 3x USB 3.2 Gen 2, 1x Ethernet (10GbE RJ-45), 1x Ethernet (GbE RJ-45), 1x line-in (3.5mm), 1x line-out (3.5mm) |
| Expansion Bays | Bay 1 supports one 3.5" HDD, standard, optional support for M.2 SSD, Bay 2 supports one 3.5" HDD, standard, optional support for M.2 SSD |
| Expansion Slots Total (Free) | 7 PCIe slots with 4x PCIe 5.0 slots and 3x PCIe 4.0 slots |
| Power | |
| Power / Device Type | Power Supply |
| Power / Provided (W) | 1400 Watt |
| Dimensions&Miscellaneous | |
| Width | 6.9 Inch |
| Depth | 20 Inch |
| Height | 17.1 Inch |
| Weight | 24.5 Kg |
| Special Feature | |
| Security Devices | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified, Kensington Security Slot, 3 x 7 mm |
| COO | MEXICO |
| UNSPSC Code | |
| UNSPSC Code | 43211515 |
