Tripp
UPC:
UNSPSC:
39121011
MFG:
SMART750LCDNC
TRIPPLITE SMART750LCDNC
Out of stock
Eaton Tripp Lite Series - UPS (rack-mountable / external) - AC 120 V - 475 Watt - 750 VA - 1-phase - valve regulated lead-acid (VRLA) - NFC, RJ-45, USB - output connectors: 8 - 2U - 19"
Product Specifications
| Primary Information | |
|---|---|
| Product Description | Eaton Tripp Lite Series - UPS - 475 Watt - 750 VA - VRLA |
| Device Type | UPS - rack-mountable / external |
| Rack Size | 19" - 2U |
| Weight | 16.8 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 120 V |
| Output Voltage | AC 120 V - 15% / + 10% |
| Power Capacity | 475 Watt / 750 VA |
| Input Connectors | 1 x power NEMA 5-15P |
| Output connectors | 8 x power NEMA 5-15R (UPS and surge) |
| Battery | Lead acid valve regulated lead-acid (VRLA) |
| Run Time (Up To) | 1 min at full load |
| Networking | NFC, RJ-45, USB |
| Remote Management Protocol | CLI |
| Included Accessories | 2-post rack mounting kit, 4-post rail rack mounting kit, mounting hardware |
| Dimensions (WxDxH) | 17.2 in x 8.3 in x 3.4 in |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Rack Size | 19" |
| Power Device | |
| UPS Technology | Line interactive |
| Input Voltage | AC 120 V |
| Frequency Provided | 50/60 Hz |
| Input Wiring | 1-phase |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 8 x power NEMA 5-15R (UPS and surge) |
| Output Voltage | AC 120 V - 15% / + 10% - 50/60 Hz |
| Power Capacity | 475 Watt / 750 VA |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 380 Joules |
| Circuit Protection | Circuit breaker |
| Efficiency | 98% at 100% Load |
| Power Factor (PF) | 0.63 |
| Battery | |
| Technology | Valve regulated lead-acid (VRLA) lead acid |
| Voltage Provided | DC 12 V |
| Run Time (Up To) | 1 min at full load ¦ 7 min at half load |
| Recharge Time | 8 hour(s) |
| Transfer Time | 4 ms |
| Features | Valve-regulated |
| Networking | |
| Remote Management Interface | NFC, RJ-45, USB |
| Remote Management Protocol | CLI |
| Expansion / Connectivity | |
| Interfaces | 1 x management (Ethernet) - RJ-45 ¦ 1 x management (USB) - 24 pin USB-C |
| Miscellaneous | |
| Included Accessories | 2-post rack mounting kit, 4-post rail rack mounting kit, mounting hardware |
| Cables Included | Power cable - integrated - 5 ft |
| Equipment Protection Value | 250000 US Dollars |
| Features | ABS housing, LCD display, brown-out protection, overvoltage protection, audible alarm, Automatic Voltage Regulation (AVR), LED indicators, auto restart, controllable load banks, overvoltage correction, undervoltage correction, cold-start function, energy saving green topology, self-test |
| Compliant Standards | Mexico NOM, UL 1778, RoHS, FCC Part 15 Class B, CSA |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% RH (non-condensing) |
| Sound Emission | 40 dB |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 8.3 in |
| Height | 3.4 in |
| Weight | 16.8 lbs |
| Special Feature | |
| COO | VIET NAM |
| UNSPSC Code | |
| UNSPSC Code | 39121011 |
