StarTech
UPC:
065030909822
UNSPSC:
43201553
MFG:
D01ML55P-FIBER-MEDIA
STARTECH GIGABIT FIBER TO RJ45 ETHERNET MEDIA CONVERTER DONGLE, OPTICAL SINGLEMODE 10KM/MULTIMODE 800M, POE POWERED
172 in stock, ready to ship
StarTech.com Gigabit Fiber to RJ45 Ethernet Media Converter, Micro Mini - Fiber media converter - 1GbE - 1000Base-LX, 1000Base-T - RJ-45 / LC single-mode / LC multi-mode - up to 6.2 miles - 1310 nm - TAA Compliant - for P/N: 50FIBLCLC10, 50FIBLCLC15, N6PATCH6BL, N6PATCH6BL10PK
Product Specifications
| Primary Information | |
|---|---|
| Product Description | StarTech.com Gigabit Fiber to RJ45 Ethernet Media Converter, Micro Mini - fiber media converter - 1GbE - TAA Compliant |
| Device Type | Fiber media converter - RJ-45 / LC single-mode / LC multi-mode |
| Form Factor | External |
| Cabling Type | 1000Base-T, 1000Base-LX |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 1310 nm |
| Data Link Protocol | 1GbE |
| Max Transfer Distance | 6.2 miles |
| Power Over Ethernet (PoE) | PoE |
| Power | DC 30 - 57 V |
| Dimensions (WxDxH) | 3.2 in x 0.8 in x 0.7 in |
| Weight | 1.48 oz |
| TAA Compliant | Yes |
| Manufacturer Warranty | 2-year warranty |
| Designed For | P/N: 50FIBLCLC10, 50FIBLCLC15, N6PATCH6BL, N6PATCH6BL10PK |
| General | |
| Device Type | Fiber media converter |
| Form Factor | External |
| Color | Silver |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-T, 1000Base-LX |
| Data Link Protocol | 1GbE |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 1310 nm |
| Max Transfer Distance | 6.2 miles |
| Status Indicators | Power, link/activity, fiber |
| Features | Metal housing, EMI protection, unmanaged, over-voltage protection, over-current protection, over temperature protection, 2KV Surge protection, Link Fault Pass-Through (LFPT) support, latching, Marvell 88E1512 chipset, auto-negotiation, auto-uplink (auto MDI/MDI-X), PoE powered |
| Compliant Standards | IEEE 802.3af, IEEE 802.3ab, IEEE 802.3z, USB 1.1 |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000Base-T - RJ-45 male ¦ 1 x Ethernet 1000Base-LX - LC single-mode / LC multi-mode female x 2 ¦ 1 x USB - Type A |
| Miscellaneous | |
| Compliant Standards | Plug and Play, IP20, WEEE, Laser Class 1 |
| TAA Compliant | Yes |
| Power | |
| Power Over Ethernet (PoE) | PoE |
| Voltage Required | DC 30 - 57 V |
| Dimensions & Weight | |
| Width | 3.2 in |
| Depth | 0.8 in |
| Height | 0.7 in |
| Weight | 1.48 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 5.4 in |
| Shipping Depth | 3.1 in |
| Shipping Height | 1.3 in |
| Shipping Weight | 2.65 oz |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 131 °F |
| Humidity Range Operating | 5 - 85% RH |
| Compatibility Information | |
| Designed For | P/N: 50FIBLCLC10, 50FIBLCLC15, N6PATCH6BL, N6PATCH6BL10PK |
| Special Feature | |
| COO | TAIWAN |
| UNSPSC Code | |
| UNSPSC Code | 43201553 |
